Jendela Alumunium - Aluminium Sliding Window Economy

Jendela alumunium dipilih banyak orang karena kekuatan dan ketahanan jendela alumunium hingga puluhan tahun. Jendela yang terbuat dari alumunium selain tidak memerlukan keahlian khusus untuk membersihkannya, namun juga memiliki banyak variasi dan bagus dipandang mata.

Jaya Mataram mengerjakan plus memasang apapun jenis jendela alumunium untuk anda. Tersedia berbagai macam variasi jendela alumunium yang pernah kami kerjakan, seperti :

  • Jendela Kaca Mati - Fixed Window
  • Jendela Engsel Atas - Top Hung Window
  • Jendela Engsel Samping - Side Hung Window
  • Jendela Engsel Bawah - Bottom Hung Window
  • Jendela Tuas Layang - Projected Window
  • Jendela Polos Datar Sentris - Horizontal Centre Pivoted Window
  • Jendela Tegak Putar Penuh - Vertical Centre Pivoted Window
  • Jendela Poros Tegak - Vertical Off Centre Pivoted Window
  • Jendela Geser Datar - Horizontal Sliding Window
  • Jendela Geser Tegak - Vertical Sliding Window

Hubungi Jaya Mataram segera untuk mendapatkan jendela alumunium berkualitas yang anda inginkan. Kami bahkan juga membuat jendela Kapal selam, kereta api, dan lain-lain.

Katalog Jendela Alumunium / Aluminium Sliding Window Economy

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2141 (Group 2136) 1.15 0.504 301.22
1391 (Group 1388) 1.25 0.540 300.43
0040 (Group 0037) 1.50 0.608 300.43

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2140 (Group 2136) 1.15 0.280 182.20
1389 (Group 1388) 1.25 0.298 175.68
0038 (Group 0037) 1.40 0.339 177.62

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2139 (Group 2136) 1.15 0.448 260.75

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2136 (Group 2136) 1.15 0.396 244.19
1388 (Group 1388) 1.25 0.415 243.19
0037 (Group 0037) 1.40 0.464 240.95

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2138 (Group 2136) 1.15 0.401 260.75
1392 (Group 1388) 1.25 0.402 236.04
0041 (Group 0037) 1.50 0.453 229.39

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2135 (Group 2136) 1.15 0.299 134.17

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2141 (Group 2136) 1.15 0.504 301.22
1391 (Group 1388) 1.25 0.540 300.43
0040 (Group 0037) 1.50 0.608 300.43

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2140 (Group 2136) 1.15 0.280 182.20
1389 (Group 1388) 1.25 0.298 175.68
0038 (Group 0037) 1.40 0.339 177.62

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1393 (Group 1388) 1.25 0.469 264.30
0668 (Group 0037) 1.50 0.540 265.27

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2136 (Group 2136) 1.15 0.396 244.19
1388 (Group 1388) 1.25 0.415 243.19
0037 (Group 0037) 1.40 0.464 240.95

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2138 (Group 2136) 1.15 0.401 260.75
1392 (Group 1388) 1.25 0.402 236.04
0041 (Group 0037) 1.50 0.453 229.39

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1386 (Group 1388) 1.25 0.329 134.82

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1387 (Group 1388) 1.25 0.390 177.08

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1390 (Group 1388) 1.25 0.397 232.62

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1385 (Group 1388) 1.25 0.189 112.87
0466 (Group 0474) 1.20 0.182 115.12
0034 (Group 0037) 1.27 0.190 113.01

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2148 (Group 2136) 1.10 0.347 181.10
0036A (Group 0037) 1.30 0.423 171.18

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2137 (Group 2136) 1.15 0.362 236.50

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0469 (Group 0474) 1.30 0.564 288.74

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0468 (Group 0474) 1.30 0.324 178.42

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0470 (Group 0474) 1.30 0.461 137.37

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0474 (Group 0474) 1.30 0.437 242.62

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1385 (Group 1388) 1.25 0.189 112.87
0466 (Group 0474) 1.20 0.182 115.12
0034 (Group 0037) 1.27 0.190 113.01

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0467 (Group 0474) 1.30 0.339 135.20
0035 (Group 0037) 1.60 0.363 134.37

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0472 (Group 0474) 1.30 0.423 171.18

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0471 (Group 0474) 1.30 0.434 241.37

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2141 (Group 2136) 1.15 0.504 301.22
1391 (Group 1388) 1.25 0.540 300.43
0040 (Group 0037) 1.50 0.608 300.43

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2140 (Group 2136) 1.15 0.280 182.20
1389 (Group 1388) 1.25 0.298 175.68
0038 (Group 0037) 1.40 0.339 177.62

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1393 (Group 1388) 1.25 0.469 264.30
0668 (Group 0037) 1.50 0.540 265.27

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2136 (Group 2136) 1.15 0.396 244.19
1388 (Group 1388) 1.25 0.415 243.19
0037 (Group 0037) 1.40 0.464 240.95

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2138 (Group 2136) 1.15 0.401 260.75
1392 (Group 1388) 1.25 0.402 236.04
0041 (Group 0037) 1.50 0.453 229.39

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
1385 (Group 1388) 1.25 0.189 112.87
0466 (Group 0474) 1.20 0.182 115.12
0034 (Group 0037) 1.27 0.190 113.01

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0467 (Group 0474) 1.30 0.339 135.20
0035 (Group 0037) 1.60 0.363 134.37

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
2148 (Group 2136) 1.10 0.347 181.10
0036A (Group 0037) 1.30 0.423 171.18

alumunium Window-Sliding Window Economy

Die NoThick (mm) W (Kg/m) Per (mm)
0039 (Group 0037) 1.40 0.442 237.95
